Endoscopes are specialized instruments used for examining the interior of a hollow organ or cavity within the body. They are essential tools in modern medical diagnostics and surgical procedures, allowing for minimally invasive access to areas that would otherwise require open surgery.

HD quality in 5.0 and 10.0 mm diameter

High-definition laparoscopes in 5.0 and 10.0 mm diameters are offered by UnivLabs. Sharp, high-contrast images with natural color rendition are delivered by our laparoscopes, making them ideal for laparoscopic applications in visceral surgery, urology, and gynecology. Available in various diameters and viewing angles to suit different surgical needs, our laparoscopes are designed for white light applications.

Quality Features of 10 mm Laparoscopes

Superior quality is ensured for 10 mm laparoscopes with a uniquely designed tip segment, where uniform, sharp-edged illumination and optimal light yield are achieved through specialized arrangement and processing of the optical fibers. To maintain long-term high quality, sensitive endoscope tips are protected through multiple measures, including the addition of a tip segment for the lens and attachment of optical fibers without stretching.

Technical Data:

WORKING Ø WORKING LENGTH DIRECTION OF VIEW FIELD OF VIEW ITEM NUMBER
10 mm 344 mm 0° wide angle UL -0500.00.292
10 mm 344 mm 30° wide angle UL -0500.00.310
10 mm 344 mm 45° wide angle UL -0500.30.302

Direction of view 0

Direction of view 30°

Direction of view 45°

High-Contrast Images with High Stability

High-contrast images with exceptional stability are delivered by UnivLabs scopes, which allow clear visualization of the inside of the uterus for diagnostic and therapeutic purposes. Equipped with advanced imaging technology and designed with precise working and irrigation channels, optimal image quality is ensured, providing healthcare professionals with reliable visual information and high level of stability.

Quality Feature

HD resolution of 1920 x 1080 pixels is transmitted by UnivLabs Scopes, facilitated by the purity of the lenses and coating. The optical systems of our laparoscopes are meticulously calculated to achieve the best possible resolution.

Technical Data:

WORKING Ø WORKING LENGTH DIRECTION OF VIEW FIELD OF VIEW
2.9mm 302 mm 12° UL -0200.30.260
2.9 mm 302 mm 30° UL -0270.00.302
4.0 mm 302 mm 12° UL -0400.00.302
4.0mm 302mm 30° UL -0400.12.302

HD Quality in 2.9 and 4.0 mm Diameter

Excellent images with natural color rendition for endoscopic examinations of the lower urinary tract are delivered by cystoscopes with 2.9 and 4.0 mm diameters. These cystoscopes are available in various viewing directions, fields of view, and working lengths commonly used in cystoscopy. Additionally, models compatible with shaft locking systems from other manufacturers are also offered.

Quality Feature

HD resolution of 1920 x 1080 pixels is transmitted by UnivLabs Scopes, achieved through contributions from the purity of the lenses and coating. The best possible resolution is calculated for all optical systems. UnivLabs Scopes are considered ideal for use with full HD cameras.

Technical Data:

WORKING Ø WORKING LENGTH DIRECTION OF VIEW FIELD OF VIEW ITEM NUMBER
2.9 mm 302 mm 0° wide angle UL -0200.30.260
2.9 mm 302 mm 30° wide angle UL -0270.00.302
4.0 mm 302 mm 0° standard UL -0400.00.302
4.0 mm 302 mm 0° wide angle UL -0400.12.302
4.0 mm 302 mm 12° standard UL -0400.25.302
4.0 mm 302 mm 30° standard UL -0400.30.302
4.0 mm 302 mm 30° wide angle UL -0400.45.302
4.0 mm 302 mm 70° wide angle UL -0400.70.302

HD Quality in 2.7 and 4.0 mm Diameter

Sharp, high-contrast images with natural color reproduction for endoscopic examination and treatment of both small joints, such as the wrist, and large joints, such as knees, shoulders, hips, elbows, and ankles, are provided by arthroscopes with 2.7 and 4.0 mm diameters. These arthroscopes are available in the commonly used directions of view, opening angles, and working lengths for arthroscopy. Additionally, models with shaft locking systems from other manufacturers are available in our range.

Quality Feature : High-Resolution Up to the Edge

UnivLabs scopes transmit HD resolution of 1920 x 1080 pixels, achieved through the purity of our lenses and specialized coatings. Each optical system is meticulously calculated to deliver the highest possible resolution. These are perfectly suited for use with full HD cameras, ensuring exceptional clarity and precision in medical imaging.

Technical Data:

WORKING Ø WORKING LENGTH DIRECTION OF VIEW FIELD OF VIEW ITEM NUMBER
2.7 mm 187 mm 0° standard UL -0190.00.065
2.7 mm 187 mm 30° standard UL -0190.00.080
2.7 mm 187 mm 70° standard UL -0190.00.090
4.0 mm 175 mm 0° wide angle UL -0190.00.098
4.0 mm 175 mm 30° wide angle UL -0190.00.104
4.0 mm 175 mm 45° wide angle UL -0190.00.110
4.0 mm 175 mm 70° wide angle UL -0190.00.112
